Purpose: Tap of Insulated Cables, suitable for combinations aluminum to aluminum, aluminum to copper and copper to copper in overhead power distribution lines (low voltage up to 1kV).
Characteristics: Insulation piercing connection (no stripping of cable insulation required). Used with 0.6/1kV XLPE/PE insulated aluminum cables or 450/750v PVC insulated cables (without cover). It has a fuse nut to ensure a perfect connection. It has elastomeric rubbers, making the connector watertight.
Application: Overhead insulated power distribution lines.
Material: Polymer connector resistant to weather and U.V. rays. Tin plated copper contacts.
Application Tool: Star or socket wrench.
Purpose: Termination of copper conductors.
Characteristics: High electrical conductivity and corrosion resistance. Pad with several hole diameter options and optimum electrical contact.
Applications: Electrical panels, circuit breaker connections, motors, machines, busbars, electrical distribution boards, among others.
Material: Electrolytic copper.
Finish: Tin plated.
Purpose: Connection between ground rod to cable and cable to cable. Suitable for COPPERSTEEL and copper wires and cables.
Characteristics: Compression connection. High resistance to corrosion. It can be buried directly into the ground or concrete.
Application: Grounding systems in general (power distribution systems, grounding grids, residential, building and industrial grounding), grounding in telecommunication networks, grounding in substations).
Material: Copper alloy, supplied with antioxide compound INTELTROX-Cu.
Purpose: Termination of rigid or flexible copper cables.
Characteristics: Compression connection. High electrical conductivity and corrosion resistance.
Application: Electrical installations in general (residential, building, industrial). Circuits up to 70ºC and 750V.
Material: Electrolytic copper and insulation in rigid PVC.
Finish: Tin plated and insulated.
Application Tool: AT-10 or ATC-6.
Purpose: Bimetallic cable to busbar termination (aluminum or ALUMOSTEEL cable to copper busbar).
Characteristics: Compression connection. Its construction (copper pad and aluminum barrel) prevents the formation of galvanic corrosion. Pad with one hole.
Applications: Power distribution lines.
Material: Electrolytic copper pad and extruded aluminum barrel. Supplied with antioxide compound INTELTROX.
Note: For installation in regions of aggressive enviroments, it is recommended to use thermoset insulation or self-fusing tape in the connection.
Purpose: Connection between ground rod to cable or IPS tube-cable. Suitable for COPPERSTEEL or copper cables.
Characteristics: Tightening connection. High electrical conductivity and corrosion resistant. It allows you to connect a cable, at 90º in relation to the rod / IPS tube.
Application: Grounding systems in general (power distribution systems, grounding grids, residential, building and industrial grounding, grounding in telecommunication networks, grounding in substations).
Material: Copper alloy clamp, fittings in copper alloy or electrolytic zinc plated steel.
Application Tool: Spanner set or open-ended wrench.
